120° solid carbide chamfer mill MC502-10.0A4L-WJ30TF

120° solid carbide chamfer mill MC502-10.0A4L-WJ30TF

€

50.33

EX VAT

€

61.91

INC VAT

Walter Prototyp

120° solid carbide chamfer mill MC502-10.0A4L-WJ30TF

= First choice

= Second choice

Delivery Information

Quantity:

ADD TO CART

PRODUCT ATTRIBUTES

Tool designation (Designation) MC502-10.0A4L-WJ30TF

Cutting edge diameter (D c) 1.5 mm

Maximum cutting diameter (D a) 10 mm

Cutting edge length (L c) 2,45 mm

Overall length (l 1) 100 mm

Maximum projection length (l 4) 59,6 mm

Connection diameter (d 1) 10 mm

Clearance angle major (α) 120 Deg

Number of teeth (Z) 4

Insert Shape MC

DESCRIPTION & FEATURES

120° solid carbide chamfer mill MC502 • Advance • metric • DIN 6535 HA shank • Dc=1,5mm • Z=4

Article number (J21):

MC502-10.0A4L-WJ30TF

Standard number of properties layout (NSM):

DIN4000-82

Company code (J3):

Tool style code (BLD):

Cutting diameter (A1):

1,5 mm

Cutting diameter maximum (A2):

10 mm

Depth of cut maximum (B2):

2,45 mm

Protruding length (B3):

59,6 mm

Overall length (B5):

100 mm

Functional length (B71):

99,6 mm

Connection code type machine side (C11):

ZYL

Connection code form at machine side (C12):

Connection code unit base machine side (C14):

Connection code style machine side (C15):

Connection size code machine side (C2):

0100

Connection diameter machine side (C3):

10 mm

ISO-tolerance class shank diameter (C31):

Shank length (C4):

40 mm

Rotational speed maximum (D6):

80000 1/min

Weight of item (D7):

0,119 kg

Tool cutting edge angle (E1):

30 °

Rake angle radial (E2):

1 °

Rake angle axial (E3):

0 °

Cutting direction (F1):

Right

Peripheral effective cutting edge count (F21):

Face effective cutting edge count (F22):

Flute helix hand (F3):

Flute helix angle (F4):

0 °

Coolant entry style code (H21):

Coolant exit style code (H22):

Grade manufacturer's designation (H3):

WJ30TF

Body material code (H4):

Coating (H5):

TiAlN

Standard (J1):

PWZ-NORM L

Standard letter to the standard number (J11):

Data chip provision (J7):

120° solid carbide chamfer mill MC502-10.0A4L-WJ30TF
