CBN – Negative round RNGN RNGN120400TM-S WBK30CBN – Negative round RNGN RNGN120400TM-S WBK30
CBN – Negative round RNGN RNGN120400TM-S WBK30 CBN – Negative round RNGN RNGN120400TM-S WBK30

CBN – Negative round RNGN RNGN120400TM-S WBK30

€
183.00
EX VAT
€
225.09
INC VAT
Walter
CBN – Negative round RNGN RNGN120400TM-S WBK30
P
H
M
S
K
N
O
= First choice
= Second choice
Delivery Information
ADD TO CART
PRODUCT ATTRIBUTES
Tool designation (Designation) RNGN120400TM-S WBK30
Diameter of inscribed circle (d) 12,7 mm
Feed per revolution (f) 0,1 - 0,4 mm
Depth of cut (a p) 0,1 - 5 mm
Insert Shape RN
DESCRIPTION & FEATURES

CBN – Negative round RNGN ...-TM-S • WBK30 • r=6,3mm

Article number (J21):
RNGN120400TM-S WBK30
Company code (J3):
W
Standard number of properties layout (NSM):
DIN4000-76
Tool style code (BLD):
10
Clearance angle major (A2):
0 °
Inscribed circle diameter (B3):
12,7 mm
Insert thickness (C1):
4,762 mm
Weight of item (D75):
0,004 kg
Cutting edge condition code (E41):
T
Chip breaker face count (E6):
0
Chip breaker manufacturers designation (E9):
TM-S
Insert hand (F1):
N
Tolerance class insert (G1):
G
Insert thickness total (G4):
4,762 mm
Insert mounting style code (G5):
1
Coolant supply property (H2):
0
Grade manufacturer's designation (H3):
WBK30
Coating (H5):
CBN
Tipped cutting edge code (H6):
S
Standard designation (J11):
RNGN120400
