Grooving module – Radial grooving G2632-E...R/L...-SX G2632-E20R-2T20SXGrooving module – Radial grooving G2632-E...R/L...-SX G2632-E20R-2T20SX
Grooving module – Radial grooving G2632-E...R/L...-SX G2632-E20R-2T20SX Grooving module – Radial grooving G2632-E...R/L...-SX G2632-E20R-2T20SX

Grooving module – Radial grooving G2632-E...R/L...-SX G2632-E20R-2T20SX

€
104.00
EX VAT
€
127.92
INC VAT
Walter
Grooving module – Radial grooving G2632-E...R/L...-SX G2632-E20R-2T20SX
P
H
M
S
K
N
O
= First choice
= Second choice
Delivery Information
ADD TO CART
PRODUCT ATTRIBUTES
Tool designation (Designation) G2632-E20R-2T20SX
Insert Shape G2
DESCRIPTION & FEATURES
Grooving module – Radial grooving G2632-E...R/L...-SX • metric • Right • SX00
Article number (J21):
G2632-E20R-2T20SX
Company code (J3):
W
Standard number of properties layout (NSM):
DIN4000-175
Tool style code (BLD):
4
Cutting width (A18):
2 mm
Functional length (A3):
41,75 mm
Functional height (A4):
16 mm
Cutting depth maximum (A8):
20 mm
Overall length (B5):
41,75 mm
Weight of item (D7):
0,031 kg
Tool cutting edge angle (E1):
90 °
Rake angle orthogonal (E4):
0 °
Inclination angle (E5):
0 °
Cutting direction (F1):
Right
Clamping type code (F5):
C
Body material code (H4):
S
Data chip provision (J7):
0
