Precision boring tool B4030.T45.07-09.Z1.WC02

Precision boring tool B4030.T45.07-09.Z1.WC02

€

2,281.00

EX VAT

€

2,805.63

INC VAT

Walter

Precision boring tool B4030.T45.07-09.Z1.WC02

= First choice

= Second choice

Delivery Information

Quantity:

ADD TO CART

PRODUCT ATTRIBUTES

Tool designation (Designation) B4030.T45.07-09.Z1.WC02

Cutting edge diameter (D c) 7.3 - 9.5 mm

Connection diameter (d 1) 45 mm

Connection size code (d 1) T45

Cutting edge length (L c) 20 - 65 mm

Minimum length (l 6 min) 30 mm

Maximum length (l 6 max) 53 mm

weight of item 0,9 kg

Insert Shape B4

DESCRIPTION & FEATURES

Precision boring tool B4030 • ScrewFit • metric • Dc=7-10mm

Article number (J21):

B4030.T45.07-09.Z1.WC02

Company code (J3):

Standard number of properties layout (NSM):

DIN4000-84

Tool style code (BLD):

Cutting diameter minimum (A11):

7,3 mm

Cutting diameter maximum (A12):

9,5 mm

Protruding length (B3):

178 mm

Overall length (B5):

213 mm

Functional length (B71):

130 mm

Connection code type machine side (C11):

SAW

Connection code form at machine side (C12):

Connection code unit base machine side (C14):

Connection code style machine side (C15):

Connection size code machine side (C2):

0450

Connection diameter machine side (C3):

45 mm

Rotational speed maximum (D6):

14000 1/min

Weight of item (D7):

0,93 kg

Tool cutting edge angle (E1):

93 °

Cutting direction (F1):

Right

Peripheral effective cutting edge count (F21):

Face effective cutting edge count (F22):

Coolant entry style code (H21):

Coolant exit style code (H22):

Body material code (H4):

Data chip provision (J7):
